Content | |
Performance | |
Communication | Wireless |
---|---|
Installation Environment | Indoor |
Compatibility | K series, K series V, X series, X series V, XR800, XR800 V |
Sensing Element | Magnetic reed switch |
Detection Technology | Magnetic |
Detection Range / Coverage | 0.01 ~ 0.02 m |
Detection Range / Coverage | 0.02 |
Detection Zones | N/A |
Detection Angle | N/A |
PIR Lens | N/A |
Activation Threshold | N/A |
Notification Type | N/A |
Siren Volume | N/A |
Alarm Period | N/A |
Alarm Type | N/A |
Motion Detection Speed | N/A |
Sensitivity | N/A |
Self Test | Life test |
Walk Test | N/A |
Microwave frequency | N/A |
Solid State Relay | N/A |
Separated Alarm & Tamper Relays | N/A |
EOL Resistors | N/A |
Creep Zone | N/A |
Anti-masking | N/A |
Anti-masking | N/A |
Anti-Sabotage and Tampering | Anti-opening tamper, Back tamper |
Pulse Counter | N/A |
Warm-up Period | N/A |
RFI Protection | N/A |
Temperature Compensation / Sensor | N/A |
Digital Analysis | N/A |
Installation Height | N/A |
Pet Immunity | N/A |
Pet Immunity | N/A |
Communication Technology | |
Radio Technologies | FSK |
Communication Range | N/A |
Communication Type | Two-way |
Operating Frequencies | 868.3 MHz |
Maximum effective radiated power | N/A |
Encryption | AES |
Rolling Code / Frequency Hopping | Rolling code |
Video | |
Video Verification | N/A |
Camera Lens | N/A |
Camera Angle | N/A |
Camera Resolution (max) | N/A |
Frame Rate (max) | N/A |
Illumination | N/A |
Wireless | N/A |
Environmental | |
Operating Temperature | 0°C ~ 40°C |
Humidity | N/A |
Ingress Protection | N/A |
Electrical | |
Input Voltage | 3 V DC |
Power Consumption | 1.2 µA (standby), 25 mA (alarm) |
Battery | Lithium, CR2025, CR3032 |
Battery Life | N/A |
Mechanical | |
Dimensions | 25.0 x 50.0 x 17.0 mm |
Net Weight | 0.18 |
Material | ABS |
Color | White |
Mounting Type | Window, Door |
Certification | |
Certificates | CE, EN 50131-2-2, Grade 2 |
Package | |
Package Contents | Installation manual |
Link to Manufacturer | www.amcelettronica.com/en |
Notes | N/A |
