What is WizSense?
Launched by Dahua Technology, WizSense is a series of wide range AI products and solutions that adopt independent AI chip and deep learning algorithm. It can recognize human and vehicle in an image with high accuracy, enabling users to focus on real targets. WizSense focuses on human and vehicle, benefiting everyone with intelligent functions, simple configuration and inclusive products.
SMD 4.0: With upgraded AI capabilities, the SMD function filters...
Content | |
Video | |
Image Sensor Type | Progressive scan CMOS |
---|---|
Image Sensor Size | 1/2.8" |
Minimum Illumination (Color) | 0.002 lux |
Minimum Illumination (B/W) | 0.0002 lux / 0 lux (LED) |
Low Light Technology | N/A |
Color Technology | Dual light, Full-color |
Lens | |
Lens Type | Fixed lens |
Focal Length | 2.8 mm |
Zoom Ratio | N/A |
Field of View (H) | 107° |
Iris Control | Fixed iris |
Pan / Tilt / Rotate | |
Pan / Tilt / Rotate Range | 0° ~ 360° / 0° ~ 78° / 0° ~ 360° |
Operational | |
Illumination | Warm LED, Smart IR LED |
Viewable Length | 30 m |
Color Mode | True day / night ICR |
Backlight Compensation | WDR, HLC, BLC |
WDR (Wide Dynamic Range) | 120 dB |
Digital Noise Reduction | 3D DNR |
Digital Image Stabilization | N/A |
Defog | N/A |
Motion Detection | Yes |
Privacy Masking | Yes |
Image Rotation | Image flip, Image mirror, Image rotation |
Control Interface | N/A |
Video Interface | N/A |
Analytics | |
AI Object Classification | Person detection, Vehicle detection |
AI Analytics | Region intrusion, Tripwire |
Intelligent Video Analytics | Motion detection, Tampering, Audio detection |
Facial Analytics | N/A |
Pre-installed Application | N/A |
Alarm | |
Alarm Input | N/A |
Alarm Output | N/A |
PIR Sensor | N/A |
Light Warning | N/A |
Audio | |
Audio Input | N/A |
Audio Output | N/A |
Built-in Microphone | Yes |
Built-in Speaker | N/A |
Audio Communication | One-way audio |
Network | |
Ethernet | RJ-45 10/100 BASE-T |
Wireless LAN | N/A |
Mobile Broadband & GNSS | N/A |
Video Compression | H.265, H.264, M-JPEG |
Smart / Wise / Zip Streaming | Smart streaming |
Maximum Resolution | 2 MP / 1920 x 1080 / Full HD 1080p |
Maximum Framerate (fps) | 30 fps / 2 MP |
Streaming Capability | Dual streaming |
Edge Storage | MicroSD |
Memory Card Slot | 1 slot |
API (Application Programming Interface) | ONVIF profile S, ONVIF profile T, CGI |
Network Storage | Network Optix Nx Witness, Milestone XProtect, Dahua DSS Pro, Dahua NVR, Dahua Hybrid DVR |
Mobile & Desktop Applications | Nx Witness Mobile, XProtect Mobile, DMSS, DSS Agile |
Environmental | |
Operating Temperature | -40°C ~ 60°C |
Humidity | < 95% |
Ingress Protection | IP67 |
Vandal Resistance | N/A |
Electrical | |
Input Voltage | 12 V DC, PoE (IEEE 802.3af) |
Power Consumption | 3.8 W (12 V DC), 4.4 W (PoE) |
Mechanical | |
Dimensions | Ø 121.9 x 99.1 mm |
Net Weight | 0.46 |
Casing material | Metal, Plastic |
Casing Color | White |
Certification | |
Certificates | CE |
Package | |
Package Contents | Quick start guide |
Related Accessory | PFA130-E, PFB205W-E, PFA152-E, PFA109, PFB220C |
Link to Manufacturer | www.dahuasecurity.com |
Notes | N/A |
mageworx-dynamic-options |
Firmware download:
You can find the current firmware on the official website of the manufacturer www.dahuasecurity.com.
In the upper right corner of the search section, you need to enter the name of the camera and find the exact model. Then look for the Firmware tab. Several firmware may be listed for each product. If they have the same name and differ only in the letters PN or NP, choose firmware with the PAL standard, and therefore PN.
If you do not want to upgrade the firmware yourself, please contact our technical support: technika@gemtech.eu
Or call the phone number: 052 7897891.
Popular tools:
ConfigTool
ConfigTool 5.1 integrates ConfigTool Batch Mode, ACS Config, VDP Config, ARC Config. lt supports Dahua devices'information check device initalization, single/batch lP modification, parameter configuration, password reset, firmware upgrade, device reset, time calibration, CGl.
Update time:2023-06-25 13:44:25
Version:V5.1.2
SmartPSS Lite
The SmartPSS Lite Client Software is designed to configure and manage Dahua devices such as IP cameras, recorders (NVRs, XVRs), access control devices (ASIs, ASCs, ASRs), attendance management devices (ASAs), and video intercom devices (VTOs, VTHs, VTSs).
Update time:04.02.2024
Version:V1.3.5
SmartPSS Lite Mac
The SmartPSS Lite Client Software is designed to configure and manage Dahua devices such as IP cameras, recorders (NVRs, XVRs), access control devices (ASIs, ASCs, ASRs), attendance management devices (ASAs), and video intercom devices (VTOs, VTHs, VTSs).
Update time:10.12.2024
Version:V1.003
If you need more help, please contact our technical support: support@gemtech.eu
Or call the phone number: 00421 52 7897891.
