Content | |
Performance | |
Communication | Wireless |
---|---|
Installation Environment | Outdoor |
Compatibility | K series, K series V, X series, X series V, XR800, XR800 V |
Sensing Element | Dual PIR sensor |
Detection Technology | Motion |
Detection Range / Coverage | 3 ~ 15 m |
Detection Range / Coverage | 15 |
Detection Zones | 18 patterns |
Detection Angle | 90° |
PIR Lens | Fresnel lens |
Activation Threshold | N/A |
Notification Type | N/A |
Siren Volume | N/A |
Alarm Period | N/A |
Alarm Type | AND |
Motion Detection Speed | N/A |
Sensitivity | Adjustable |
Self Test | Test function |
Walk Test | Walk test |
Microwave frequency | N/A |
Solid State Relay | N/A |
Separated Alarm & Tamper Relays | Yes |
EOL Resistors | N/A |
Creep Zone | N/A |
Anti-masking | N/A |
Anti-masking | N/A |
Anti-Sabotage and Tampering | Anti-opening tamper, Back tamper |
Pulse Counter | Yes |
Warm-up Period | N/A |
RFI Protection | 30 V/m |
Temperature Compensation / Sensor | Temperature compensation |
Digital Analysis | Yes |
Installation Height | 0.8 ~ 1.2 m, 1.8 ~ 2.1 m |
Pet Immunity | Yes |
Pet Immunity | Yes |
Communication Technology | |
Radio Technologies | FSK |
Communication Range | N/A |
Communication Type | Two-way |
Operating Frequencies | 868.3 MHz |
Maximum effective radiated power | N/A |
Encryption | AES |
Rolling Code / Frequency Hopping | Rolling code |
Video | |
Video Verification | N/A |
Camera Lens | N/A |
Camera Angle | N/A |
Camera Resolution (max) | N/A |
Frame Rate (max) | N/A |
Illumination | N/A |
Wireless | N/A |
Environmental | |
Operating Temperature | -30°C ~ 55°C |
Humidity | N/A |
Ingress Protection | IP65 |
Electrical | |
Input Voltage | 3.6 V DC |
Power Consumption | 12 µA (standby), 26 mA (alarm) |
Battery | Lithium, 1/2 AA |
Battery Life | N/A |
Mechanical | |
Dimensions | 185.0 x 85.0 x 66.0 mm |
Net Weight | 0.27 |
Material | ABS |
Color | White |
Mounting Type | Wall |
Certification | |
Certificates | CE, EN 50131 |
Package | |
Package Contents | Installation manual |
Link to Manufacturer | www.amcelettronica.com/en |
Notes | N/A |
