Content | |
Interface | |
Data Input Port | 1x 10/100/1000 Mbps, 1x 1000BASE-X SFP |
---|---|
PoE Data Output Port | 1x 10/100/1000 Mbps |
Performance | |
PoE Output | 83 W |
PoE Output | 83.000000 |
Standards | IEEE 802.3ab 1000BASE-T Gigabit Ethernet |
PoE Standards | IEEE 802.3af up to 15.4 W, IEEE 802.3at up to 30 W, Hi-PoE up to 60 W |
Power Supply Type | Midspan |
Environmental | |
Operating Temperature | -40°C ~ 65°C |
Humidity | < 90% |
Ingress Protection | IP20 |
Electrical | |
Input Voltage | 100 ~ 240 V AC, 2 A |
Power Consumption | N/A |
Power Output | 55 V DC, 1.5 A |
Surge Protection CM / DM | 6 kV |
Mechanical | |
Dimensions | 213.9 x 134.0 x 41.0 mm |
Net Weight | 1.10 |
Casing material | Metal |
Casing Color | Black |
Mounting Type | Wall mount, Desktop |
Certification | |
Certificates | CE, RoHS |
Package | |
Package Contents | N/A |
Link to Manufacturer | www.hanwhavision.com |
Notes | N/A |
mageworx-dynamic-options |
Download firmware:
You can always find the current firmware on the manufacturer's official website www.hanwhavision.com
In the search section, you need to enter the name of the camera and find the exact model. You will then search for the Download - Firmware tab.
